Specifications
JIC stands for Joint Industry Council and is manufactured according to the SAE J514 standard.
Also known as 37° flare fittings, they are widely used in hydraulic oil systems due to their excellent leak prevention, pressure resistance, and ease of maintenance.
Features
- Size Range: 1/4" ~ 2-1/2"
- Design Standards: SAE J514 / ISO 8434-2
- Materials: Steel / Stainless Steel / Brass
- Working Pressure: Up to 430 bar
- Operating Temperature:
Carbon Steel Fittings: -20°C ~ +120°C - Stainless Steel Fittings: -60°C ~ +200°C
